360X1120 Ouli CE Certificate Three Rubber Roll Calender/ Rubber Calender Machine to Calending Rubber

Basic Info.

Model NO.	XY-360X1120
Condition	New
Customized	Customized
Automatic Grade	Automatic
Structure	Vertical
Cutter	with 2 Cutter
Lubrication	Automatit Lubrication
Shaft	Sigle or Double Shaft
Hydraulic Brake	Yes
Calending Thickness	0.2mm
Gear Box Brand	Top in China
Bush	Rolling Bearing
Motor Brand	Top in China
Roller Material	Cast Iron
Product Name	Rubber Calender
Transport Package	Shipping Standard Packaging
Specification	20 CBM
Trademark	OULI
Origin	China
HS Code	8477800000
Production Capacity	300 Sets Per Year

Product Description

360X1120 OULI Ce Certificate Three Rubber Roll Calender/ Rubber Calender Machine to calending Rubber 1.1 Photos of 360X1120 OULI Ce Certificate Three Rubber Roll Calender/ Rubber Calender Machine to calending Rubber

1.2 Parameters of 360X1120 OULI Ce Certificate Three Rubber Roll Calender/ Rubber Calender Machine to calending Rubber

Specification & Type	Roll Dia.×Length(mm)	Mid-roll Liner Speed(m/min)	Min.thickness for calendering(mm)	Calendering width(mm)	Motor power(KW)	Overall dimension (L×W×H)(mm)	Weight(t)
XY-3-230*630	230*630	0.8-8	≥0.20	500	7.5	3168*1150*1650	3000
XY-3 -250*720	250*720	2-15.9	≥0.20	580	22	3950*1220*1870	5500
XY-3-300*900	300*900	2-17	≥0.20	700	30	4200*1500*1950	9000
XY-3-360*1120	360×1120	2-20	≥0.20	920	45	5500×1500×2340	14000
XY-3-400*1200	400*1200	3-26.39	≥0.20	1000	55	6300*1500*2440	18000
XY-3-450*1400	450×1400	3-26.2	≥0.20	1200	75	6650*2200*2900	21000
XY-3-560*1650	560*1650	3-30	≥0.20	1300	90	7350*2300*3060	28000
XY-3-610*1730	610×1730	4-40	≥0.20	1500	160	8040×2700×4570	42000

1.3 Application of three roll rubber calender machine

Rubber calender is the basic equipment in the process of rubber products, it is mainly used to put rubber on fabrics, to rubberize fabrics, or to make rubber sheet.

1.4 Features of three roll rubber calender machine

1. This machine is made of two or more rolls, arranged in a certain form. Under a certain temperature, it can calender rubber or plastic products into sheets with a certain thickness and shape, and it also can rubberize the fiber curtain canvas or steel cord.

2. According to the number of the rolls, it can be divided into 2-roll, 3-roll, 4-roll calendar, etc.

3. according to the arrangement of the rolls, it can be divided into "L" type, "T" type, "F" type, "Z "type and" S "type, etc.

The rolls are made of chilled alloy cast iron with bored cavities and can be heated by steam or cooled by water homogenously to meet different requirements.

The machine is consisted of bedplate, frame, rolls , motor , coupling ,speed -ratio gear , adjusting spacing device , the adjusting temperature device of roll .

The bedplate is whole model, Installation convenience.

1.5 Configure of three roll rubber calender machine
1. Rolls: Chilled Alloy Cast Iron rolls with surface hardness 68~72HS. The Rolls are mirror finished & polished, duly grinded and are hollowed for cooling or heating.2. Roll Clearance Adjusting Unit: Nip adjustment at two roller ends is done manually using two separate screws attached to the brass housing body.3. Roll Cooling: Universal Rotary joints with inner Spray pipes with Hoses and Headers. Piping is complete up to supply pipe terminal.4. Journal Bearing Housing: Heavy Duty Steel Casting Housing fitted with Anti Friction Roller Bearings.5. Lubrication: Full Automatic Grease lubrication pump for Anti Friction Roller Bearings fitted in dust sealed housing6. Stand Frame & Apron: Heavy Duty Steel Casting.7. Gearbox: Hard-tooth reduction gearbox, GuoMao brand.8. Base Frame: Common base frame heavy duty, Steel channel and MS plate fabricated accurately machined on which whole machine with Gearbox and motor are fitted.9. Electric Panel: Star Delta Electric operating panel with Auto Reversing, Voltmeter, Ampere, Overload protection relay, 3 Phase Indicator and Emergency Stop Switch.
A.Electric box of rubber calender B.Roller of rubber calender C. Gear box and hydraulic brake of rubber calenderD. Cutter of rubber calender machine E.Lubrication of rubber calender 2.OULI Company information (QINGDAO OULI MACHINE CO.,LTD)
